Front view
|
 |
Front view
* – it requires an additional agreement (marked in red)
The Manufacturer reserves the right to make alterations in the specifications
| Kansas A1SG 065 HT 2HD 210-D1000A-132 |
Kansas A1SG 065 MT 2HD 210-D1000A-132* |
Kansas A1SG 075 HT 2HD 210-D1200A-132 |
Kansas A1SG 075 MT 2HD 210-D1200A-132* |
Kansas A1SG 085 HT 2HD 210-D1600A-132 |
Kansas A1SG 085 MT 2HD 210-D1600A-132* |
||
| Length | mm | 1320 | 1320 | 1320 | |||
| Height | mm | 2100 | 2100 | 2100 | |||
| Depth | mm | 650 | 750 | 850 | |||
| Depth of shelf | mm | 670 | 570 | 670 | |||
| Internal capacity | l | 1150 | 1350 | 1550 | |||
| Effective capacity | l | 1100 | 1300 | 1500 | |||
| Area of display part | m2 | ||||||
| Required space | m2 | 0,86 | 0,99 | 1,12 | |||
| Door opening type | hinged | hinged | hinged | ||||
| Permissible load on the shelf | kg | ≤ 55 | ≤ 55 | ≤ 55 | |||
| Shelf type | wire | wire | wire | ||||
| Ambient temperature | ºС | ≤ +25 | ≤ +25 | ≤ +25 | |||
| Humidity | % | ≤ 60 | ≤ 60 | ≤ 60 | |||
| Effective capacity temperature | ºС | 0…+8 | -5…+5 | 0…+8 | -5…+5 | 0…+8 | -5…+5 |
| Temperature class | M1/M2/H1 | M1/M2/H1 | M1/M2/H1 | ||||
* – it requires an additional agreement (marked in red)
The Manufacturer reserves the right to make alterations in the specifications.
